Principal Features
■ 2 x 61-note tracker touch keyboards with touch
sensitivity for orchestral voices
■ 32-note radiating and concave pedalboard
■ 47 speaking stops with hundreds of alternatives
from internal memory bank
■ Illuminated rocker tabs
■ 4 preset organ styles – English, Baroque, Romantic
and Symphonic
■ 4 adjustable user styles
■ 18 alternative temperaments
■ Tremulants fully adjustable for speed and depth
Playing Aids
■ Swell expression pedal
■ Crescendo pedal programmable over 16 steps
■ 6 general pistons duplicated by toe pistons
■ 16 capture memories
■ 6 thumb pistons to Swell and Great
■ Gt/Ped, Sw/Ped, Sw/Gt reversible thumb pistons
■ Gt/Ped, Sw/Ped, Sw/Gt reversible toe pistons
■ Gt and Ped combinations coupled
■ 2 sequencer previous and next pistons
■ Gt/Sw keyboard inversion
■ Transposer with –6/+5 semitone range
Display and Software Features
■ Backlit display with 8 control buttons to access
all organ Styles and set-up features
■ Fully upgradable software platform via USB socket
■ Record and Playback using USB or Internal Memory
Dimensions and Finishes
■ Dark, Medium or Light oak wood veneer console
with solid wooden roll top cover
■ Illuminated music desk
■ 162 cm (W) x 125 cm (H) x 70 cm (D), 111 cm
(with pedalboard)
■ Weight – 185 kg
Audio System and Sound Management
■ 9 internal speakers split across 5 channels
■ 4 x 60 watt and 1 x 100 watt amplifiers
■ Stop-by-stop selection of simulated wind chest
layout
■ Stop-by-stop and divisional volume controls
■ Stop-by-stop tonal adjustment using
6 voicing parameters
■ Internal 5-band graphic equaliser
■ Fully adjustable reverberation with live
acoustic selection
■ Stereo headphone output socket
■ External outputs for up to 13 independent
audio channels
